BEZZERA MAGICA BRÜHGRUPPE WASSER DAMPFHAHN BIS 28.01.2014

Drawing number 8073534

Under the exploded drawing you can order individual items.
If your article is not listed, please use the following form and enter the desired position numbers.

Request for unlisted item numbers.

Pos.: Image: Description: Qty.:
1knob m8x1 8003294
KNOB M8x1
6,56 €

excl. Shipping costs

immediately available, 3 available
2bezzera ueberwurfmutter 3 8 quot g h17 8079315
Bezzera Überwurfmutter 3/8"G H17
13,72 €

excl. Shipping costs

immediately available, 7 available
3bezzera kippventilachse m8 stift fuer wasser dampfhahn bezzera inox 8071554
Bezzera Kippventilachse M8 Stift für Wasser/Dampfhahn Bezzera INOX
13,90 €

excl. Shipping costs

immediately available, 15 available
5feder d8 h17 aisi302 8072133
Feder D8 H17 AISI302
3,32 €

excl. Shipping costs

immediately available, 6 available
6scheibe d11 h1 5aisi303 8071592
Scheibe D11 H1.5AISI303
3,72 €

excl. Shipping costs

immediately available, 15 available
7o ring 0121 epdm 8014882
O-RING 0121 EPDM
1,07 €

excl. Shipping costs

immediately available
8spring o 11 7x16 mm 8069864
SPRING ø 11,7x16 mm
2,11 €

excl. Shipping costs

immediately available, 6 available
9teflonpfanne bezzera o 13x6x6 mm 8125571
Teflonpfanne Bezzera ø 13x6x6 mm
3,80 €

excl. Shipping costs

immediately available
10pipe steam complete satinless steel 8069460
PIPE STEAM COMPLETE SATINLESS STEEL
40,61 €

excl. Shipping costs

immediately available, 1 available
11heisswasserlanze bezzera 8072870
Heisswasserlanze Bezzera
59,74 €

excl. Shipping costs

Delivery time 4-6 weeks
12conical ptfe seal o 12x5x5 5 mm 8001409
CONICAL PTFE SEAL ø 12x5x5,5 mm
2,30 €

excl. Shipping costs

immediately available, 10 available
13bezzera steam tap without wand 8081421
Bezzera steam tap without wand
59,90 €

excl. Shipping costs

immediately available, 3 available
16deckel fuer auslaufgruppe o 16 mm 8006373
Deckel für Auslaufgruppe ø 16 mm
8,33 €

excl. Shipping costs

immediately available, 13 available
17ptfe flat gasket o 16x22 5x2 mm 8001581
PTFE FLAT GASKET ø 16x22,5x2 mm
1,65 €

excl. Shipping costs

immediately available
18water filter o 8 5x22 mm 8001115
Water filter ø 8,5x22 mm
1,79 €

excl. Shipping costs

immediately available, 17 available
19nozzle m6x1 hole 8006971
NOZZLE M6x1 HOLE
4,46 €

excl. Shipping costs

immediately available, 20 available
20chromium plated upper sleeve 8063314
CHROMIUM-PLATED UPPER SLEEVE
39,00 €
39,00 €

excl. Shipping costs

immediately available, 2 available
21injector d 0 7 upper sleeve assy 8072858
INJECTOR D.0.7 UPPER SLEEVE ASSY
71,40 €

excl. Shipping costs

Delivery time
is determined
22o ring 0128 viton 8001794
O-RING 0128 VITON
1,68 €

excl. Shipping costs

immediately available
23ptfe flat gasket o 35x30x2 mm 8001583
PTFE FLAT GASKET ø 35x30x2 mm
1,09 €

excl. Shipping costs

immediately available
24spring o 14x45 mm 8003820
SPRING ø 14x45 mm
1,57 €

excl. Shipping costs

immediately available
25complete spout valve 8007091
COMPLETE SPOUT VALVE
7,90 €

excl. Shipping costs

immediately available
26original bezzera e61 bruehgruppenkorpus 8072859
Original Bezzera E61 Brühgruppenkorpus
205,00 €

excl. Shipping costs

Delivery time 4-6 weeks..
27coffee group gasket 80x70x2 mm 8001624
COFFEE GROUP GASKET 80x70x2 mm
3,51 €

excl. Shipping costs

immediately available, 14 available
28 8071616
TIRANTE M8X31 ASTM A 193 B8 C/1
Price on request
29hexagonal nut m8 medium 8011323
HEXAGONAL NUT M8 MEDIUM
1,04 €

excl. Shipping costs

immediately available, 4 available
30ptfe flat gasket o10x6x1 mm 8001400
PTFE FLAT GASKET ø10x6x1 mm
1,30 €

excl. Shipping costs

immediately available, 16 available
31low cylinder head screw m6x10 uni 9327 8001293
LOW CYLINDER HEAD SCREW M6x10, UNI 9327
2,49 €

excl. Shipping costs

immediately available
32cam locking stainless steel screw m6 8001289
CAM LOCKING STAINLESS STEEL SCREW M6
4,03 €

excl. Shipping costs

immediately available, 12 available
33cam rod for e61 coffee group 8005124
Cam rod for E61 coffee group
11,90 €

excl. Shipping costs

immediately available
34assy flangia porta camme 8072861
ASSY FLANGIA PORTA CAMME
48,79 €

excl. Shipping costs

Delivery time 4-6 weeks..
35knob m8x1 8003294
KNOB M8x1
6,56 €

excl. Shipping costs

immediately available, 3 available
36bezzera e61 bezugshebel ohne knebel 8072857
Bezzera E61 Bezugshebel ohne Knebel
39,00 €

excl. Shipping costs

Delivery time 4-6 weeks
37zahnscheibe 0 8 nockenwelle e61 8073573
Zahnscheibe 0,8 Nockenwelle E61
1,25 €

excl. Shipping costs

immediately available
38chromium plated cap m6 8002794
CHROMIUM-PLATED CAP M6
3,51 €

excl. Shipping costs

immediately available, 5 available
39complete drain valve 8007124
COMPLETE DRAIN VALVE
9,90 €

excl. Shipping costs

immediately available
40spring guide bushing 8001795
SPRING GUIDE BUSHING
4,64 €

excl. Shipping costs

immediately available, 4 available
41outlet chromium plated sleeve 8000146
OUTLET CHROMIUM-PLATED SLEEVE
46,68 €

excl. Shipping costs

immediately available, 1 available
42e61 drain valve with gasket 8007125
E61 drain valve with gasket
5,90 €

excl. Shipping costs

immediately available
43feder o 14 6x34 mm fuer e61 auslassventil verstaerkte variante fuer vibrationspumpenmaschinen 8281551
Feder ø 14,6x34 mm für E61 Auslassventil - verstärkte Variante für Vibrationspumpenmaschinen
2,68 €

excl. Shipping costs

immediately available
44drain jet swirl 8005864
DRAIN JET SWIRL
2,78 €

excl. Shipping costs

immediately available, 11 available
45flat gasket ptfe o 26x21x2 mm 8001415
Flat gasket PTFE ø 26x21x2 mm
2,32 €

excl. Shipping costs

immediately available
46drain chromium plated fitting 8005865
DRAIN CHROMIUM-PLATED FITTING
4,40 €

excl. Shipping costs

immediately available, 3 available
47group spray nozzle o 30 mm m10x1 e61 8006987
Group spray nozzle ø 30 mm M10x1 - E61
6,14 €

excl. Shipping costs

immediately available
48shower screen fuer e61 brew unit 8000608
Shower screen für E61 brew unit
5,20 €

excl. Shipping costs

immediately available
49filter holder gasket o 73x57x8 mm 8001902
FILTER HOLDER GASKET Ø 73x57x8 mm
3,47 €

excl. Shipping costs

immediately available
50ecm rocket anschluss nockenwelle e61 verchromt hochglanzpoliert 8101292
ECM / Rocket Anschluss Nockenwelle E61 verchromt hochglanzpoliert
19,90 €

excl. Shipping costs

immediately available, 10 available
51epdm flat gasket 15 5x7 5x4 mm 8001570
EPDM flat gasket 15,5x7,5x4 mm
0,90 €

excl. Shipping costs

immediately available
52cam guide bushing 8001571
CAM GUIDE BUSHING
3,90 €

excl. Shipping costs

immediately available, 11 available
53spring o 14 6x21 mm 8003547
SPRING ø 14,6x21 mm
6,89 €

excl. Shipping costs

immediately available
54stuffing gland chrome plated fitting 8006414
STUFFING GLAND CHROME-PLATED FITTING
7,87 €

excl. Shipping costs

immediately available, 3 available
55burn preventing rubberpiece o 10 mm 8001467
Burn preventing rubberpiece ø 10 mm
2,63 €

excl. Shipping costs

Delivery time
is determined
56steam tip bezzera 4 holes inox 8072726
Steam tip Bezzera 4 holes inox
15,26 €

excl. Shipping costs

immediately available, 7 available
57steam tip 2 holes inox 8069913
Steam Tip 2 holes inox
11,31 €

excl. Shipping costs

immediately available, 2 available
59dichtung bezzera fuer dampfduese d4 5x1 5 nbr70 8072908
Dichtung Bezzera für Dampfdüse D4,5X1,5 NBR70
1,20 €

excl. Shipping costs

immediately available, 8 available
60epdm flat gasket 11x4x4 mm 8001656
EPDM FLAT GASKET 11x4x4 mm
0,55 €

excl. Shipping costs

immediately available
61dichtungstraeger kippventil bezzera d12x12 ot 8071504
Dichtungsträger Kippventil Bezzera D12X12 OT
5,88 €

excl. Shipping costs

immediately available, 7 available
62fitting m14xm13 for steam tap and hot water tap form 05 10 2012 bezzera 8081420
Fitting M14xM13 for steam tap and hot water tap (form 05.10.2012) Bezzera
This article is no longer available
63bezzera steam tap without wand 8081421
Bezzera steam tap without wand
59,90 €

excl. Shipping costs

immediately available, 3 available
64stift fuer dampf wasserhahn d12x47 5 m4 8071591
Stift für Dampf- Wasserhahn D12x47,5 M4
15,47 €

excl. Shipping costs

immediately available, 6 available
65bezzera kippventilachse m8 stift fuer wasser dampfhahn bezzera inox 8071554
Bezzera Kippventilachse M8 Stift für Wasser/Dampfhahn Bezzera INOX
13,90 €

excl. Shipping costs

immediately available, 15 available
66dichtung bezzera d6 4x1 9 nbr70 8072909
Dichtung Bezzera D6,4X1,9 NBR70
1,92 €

excl. Shipping costs

immediately available, 14 available
67pipe steam complete satinless steel 8069460
PIPE STEAM COMPLETE SATINLESS STEEL
40,61 €

excl. Shipping costs

immediately available, 1 available
68dichtung bezzera d6 4x1 9 nbr70 8072909
Dichtung Bezzera D6,4X1,9 NBR70
1,92 €

excl. Shipping costs

immediately available, 14 available
69dampfduese bezzera 2 loch edelstahl ab 26 01 2012 8069914
Dampfdüse Bezzera 2-Loch Edelstahl (ab 26.01.2012)
7,98 €

excl. Shipping costs

Delivery time 4-6 weeks..
70bezzera fitting m f m13x1 8079534
Bezzera Fitting M/F M13x1
3,67 €

excl. Shipping costs

immediately available, 6 available

If your article is not listed, please use the following form and enter the desired numbers.

Request for unlisted item numbers.
